Outdoor Connection Breakaway Gazebo with Canopy

$179.95
SKU BTG10

Breakaway Gazebo 3.0

This strong and sturdy 3 x 3m gazebo is perfect for camping, temporary shade in the back yard, picnics or a market stall.

It is quick and simple to erect and the high-quality canopy provides excellent shade and waterproofing.

Features:

  • Strong 420D, 280gsm canopy fabric with grey PVC coating on the underside ‚Äď UPF 50+
  • Canopy Fabric is treated with Fire Retardant to USA CPI-84 standards
  • Waterproof canopy with a very high 5000mm+¬†waterhead and heat-sealed taped seams
  • Higher apex makes the gazebo cooler and aids in water run-off helping prevent pooling
  • Strong steel frame with Durable powder coated hammer-tone coating
  • 4 height settings with simple push button adjustment
  • Wheeled carry bag with heavy duty 800D fabric
  • Pegs and adjustable guy ropes supplied
  • 1 year warranty
  • 2 sizes 3m x 3m (measured at the canopy) and 6x 3m
  • Optional Solid and mesh walls available
  • Solid walls have the same 420D 280gsm waterproof fabric as the canopy







    Specifications:

    Frame
    Sizes (at top of Frame) 3000 x 3000mm
    Legs  30 x 30mm
    Leg Wall Thickness 0.8mm
    Struts  Oval 13.5*23mm
    Strut Wall Thickness 0.6mm
    Frame weight 20kg
    Apex height  320m   /  329cm  /    338cm   /   347cm
    Leg heights - 4 heights
    (top of pole to foot)
    219cm  /   228cm   /   237cm  /   246cm
    Height to bottom edge of canopy 187cm   /   196cm   /   205cm  /    214cm
    Bottom edge of canopy to apex 133cm
    Foot Plate  Steel 3mm thick with 2 X 10mm peg holes
    Pole fittings
         - Top sliding bracket Push button
          - Leg height adjuster Push Button
    Paint Finish Grey Hammertone

    Canopy
    Fabric  420D polyester    with USA CPI-84 Fire Retardant
    Colour Blue
    Coating on underside Grey PVC
    Fabric weight 280gsm
    Canopy weight 4.1kg
    Seal sealing Heat sealed tape over canopy seams
    Guy Rope attachment D ring and webbing sewn onto corner
    Velcro velcro sewn continuous around bottom edge of valance for walls
    Valance height  32cm

    Carry Bag
    Fabric  800D Polyester
    Fabric Weight 380gsm
    Wheels Wheeled Carry Bag
    Instructions Sewn into Carry Bag

    Included Accessories
    Pegs 8 pegs 23cm x 6mm
    Guy Ropes  4 guy ropes with rope runners x 3m
